The Spot Spectral Confocal Measurement Microscope (SSCM) is a non-contact, sub-micron displacement measurement system that can measure the displacement or thickness of diffuse or mirror reflective surfaces and even transparent materials. Due to the coaxial nature of the output and return signal paths, the SSCM is also suitable for deep/blind hole applications.

Product Features

——

1.Objective lens can choose independent interface, also can choose 6 holes nose wheel module connection.

2. Adaptable to both domestic and international mainstream objective lenses.

3. Spectral confocal module has simple structure, high measurement accuracy and fast speed.

4. The most suitable for the observation of the surface of the high reflectivity of the surface, the same applies to the surface of transparent objects.

5. Supports differential interference observation.

6. Can be integrated with the motion control unit to achieve high-speed precision focusing

7. Spectral confocal module measurement and the main imaging optical path co-axial, there is no blocking problem, and focus detection spot is small, can be slots, holes, pits and other areas of accurate measurement.

Areas of application

——

Widely used in electronics, semiconductor, panel, equipment and other industries. Measurement of height, segment difference, thickness, flatness, contour of glass, ceramics, mirrored metal, such as cell phones, PCB, tempered glass screen protector, semiconductor wafers.
