3D QMS-342 Profile Measurement Solution

Cantilever construction,cast aluminum body,equipped with 6.5X zoom measurement module for clearer images and sharper edges for precision products.

3D QMS-342

Download now

Product Features

1. Cantilevered structure,cast aluminum body,with silent level drive platform,to ensure the operation precision and stability of the equipment.

2. Equipped with 6.5X zoom measurement module,the image is clearer and the edges are sharper for precise products.

3. Equipped with self-made point spectrum module as standard,it can measure 3D dimensions of products and realize continuous scanning and data collection without stopping,which is efficient and convenient.

4. Equipped with 3DOS vision measurement software to meet GD&T geometric tolerance and traditional 2D/3D dimensional fast measurement.

Application Cases

Very suitable for measuring distance engraving,radius,angle,radian and other dimensions of the inspection,suitable for electronics, machining,hardware,

material processing,automotive and other industries.
