16K line-scan lens PMS-LLC3-14640M-M72

PMS-LLC3-14640M-M72

POMEAS 16K line-scan lens supports up to φ82mm image, ultra-low distortion, anti-vibration design, and reference magnification covering 0.22X~3.5X.

16K-line-scanlens PMS-LLC3-14640M-M72

Product Introduction:

PMS-LLC3-14640M-M72 supports up to φ82mm image, ultra-low distortion, anti-vibration design, and standard magnification range 2.7X ~ 3.5X.

Product Advantage:

1. High resolution optical design, target size ∅82mm

2. Compatible with 5~10 μm line array cameras;

3. High uniformity, low distortion, high resolution;

4. Suitable for machine vision industry and automation industry.

Description:
