Online digital rangefinder, with its high speed, high accuracy and high durability, has been widely used in many fields. Its rich functions not only meet various measurement needs, but also improve the efficiency and accuracy of measurement.

1. Outside diameter measurement function

The in-line digital rangefinder is equipped with a special measurement mode that enables easy measurement of large diameter objects or large sheet materials. This function eliminates the need for complex calculations or other cumbersome settings to obtain fast and accurate measurement results.

2. Simultaneous measurement of the outer diameter and eccentricity of the copy cylinder

The simultaneous measurement of outer diameter and eccentricity with a single measuring head is another highlight of the in-line digital rangefinder. This dual-mode measurement greatly improves the efficiency and accuracy of the measurement, which is especially suitable for the occasions that need to pay attention to these two parameters at the same time.

3. IC wire spacing measurement

The measurement area of the on-line digital rangefinder can be flexibly designed according to the inspection purpose, such as measuring the gap or spacing of IC wires. This feature is critical for areas such as semiconductor manufacturing to ensure product quality and performance.

4. Width or glass plate edge position inspection

Even when confronted with transparent objects that are difficult to detect with conventional micrometers, such as glass plates, the in-line digital rangefinder can handle them with ease. Its edge detection level can be easily adjusted by the controller to ensure the accuracy and stability of the measurement.

5. String OD measurement (e.g. fiber optics, wires, ropes, etc.)

The In-Line Digital Distance Measuring Instrument continuously measures the outside diameter of a product and not only displays the value, but also provides a graphical representation of the trend of the measured value as represented by the waveform. This feature is very useful in situations where changes in OD need to be monitored over a long period of time, and can help the user identify potential problems in a timely manner.

6. Numerical recording and outlier analysis

Online digital distance meter also has a numerical value recording function, can record the history of abnormal values, including date, time, measured values and comparison results. These data can be saved in the controller's memory, which is convenient for users to carry out subsequent analysis and processing.
