The online projected image dimensional measuring instrument is an advanced measuring equipment designed to meet the needs of high-precision online inspection. It is able to flexibly use a variety of measuring tools according to different combinations, widely covering a variety of measurements involved in the on-line inspection process, including but not limited to dimensional measurements, geometric tolerance measurements, defect distance measurements, etc., which provides an efficient and accurate solution for the quality control and inspection process in industrial production.

The field of machine building:

1、Parts Inspection: It can be used for size measurement, geometric tolerance measurement and defect distance measurement of various parts in the machinery manufacturing industry such as automobile, aerospace and shipbuilding. For example, crankshafts, cylinder heads, pistons and other parts in automobile manufacturing; aircraft engine blades, wing connectors and other key components in the aerospace field, to ensure that their dimensional accuracy and geometric shape in line with the design requirements, to protect the performance and safety of machinery.

2、Mould manufacturing: In the process of mould manufacturing, the dimensional accuracy of the mould is required to be extremely high. The measuring instrument can be used for the measurement of cavity size, core size, demoulding inclination and other parameters of the mould, which can help the mould maker to find out the dimensional deviation and defects in the mould manufacturing process in time, and improve the quality and production efficiency of the mould.

3、Tool manufacturing: the dimensional accuracy and geometry of the tool directly affects its cutting performance and service life. The online projection image size measuring instrument can measure the cutting edge length, cutting edge angle, shank diameter and other parameters of the tool accurately to ensure that the quality of the tool meets the requirements.

Electronics Manufacturing:

1、Electronic component measurement: It is suitable for the size measurement of various electronic components, such as capacitors, inductors, resistors, chips and so on. It can accurately measure the pin length, pin spacing, chip size and other parameters of electronic components to ensure the quality and performance of electronic components and provide a reliable basis for the production of electronic products.

2、Circuit board inspection: In the process of circuit board manufacturing, it is necessary to strictly control the circuit board's line width, line spacing, aperture diameter and other parameters. The measuring instrument can quickly and accurately measure various dimensional parameters on the circuit board, detect the manufacturing quality of the circuit board, and timely detection of line short circuits, circuit breakers and other defects.

Semiconductor manufacturing field:

1、Leadframe Measurement: As the chip carrier of integrated circuits, the dimensional accuracy and quality of leadframes are crucial to the performance and reliability of semiconductor devices. Online projection image size measuring instrument can accurately measure the size, shape, position and other parameters of the lead frame to ensure that the quality of the lead frame meets the requirements.

2、Wafer Inspection: In the wafer manufacturing process, the diameter, thickness, flatness and other parameters of the wafer need to be tested. The measuring instrument can measure the dimensional parameters of the wafer in a non-contact way to avoid damage to the wafer and improve the production efficiency and quality of the wafer.

Medical Industry:

1、Medical device manufacturing: For example, in the manufacturing process of artificial joints, dental implants, pacemakers and other medical devices, the dimensional accuracy and geometry of medical devices need to be strictly controlled. Online projection image size measuring instrument can measure the key dimensions and shapes of medical devices to ensure the quality and safety of medical devices.

2、Medical supplies testing: such as syringes, infusion sets and other medical supplies, the dimensional accuracy and quality is directly related to the patient's health and safety. The measuring instrument can measure the tube diameter, needle length, needle tip angle and other parameters of medical supplies to detect the manufacturing quality of medical supplies.

Other areas:

1、Plastic products industry: It can be used for size measurement and defect detection of plastic products, such as thickness measurement of plastic film, outer diameter measurement of plastic pipes, shape measurement of plastic parts, etc., which can help plastic products enterprises to improve product quality and production efficiency.

2、Rubber products industry: It can be used for dimensional measurement and defect detection of rubber products such as rubber sealing ring and rubber tyre, such as the measurement of inner diameter, outer diameter, cross-section size and other parameters of rubber sealing ring, and the measurement of tread depth, tread width and other parameters of rubber tyre, to ensure that the quality of rubber products meets the requirements.
